iX-1200/600 series
intelligence X-ellence Station
Embedded Smooth Drive ControlTM
New motor control technology enhances prism tracking!
- World’s fastest!* New Ultrasonic motor direct drive
- World’s smallest!* Highly mobile super compact body
- World’s lightest!* 5.7kg robotic total station
- Best in class with Topcon manufacturing quality
- Compatible with ICT construction solutions!
*Based on Topcon’s testing and research August 2020.
New motor control technologies for auto-tracking!
Newly adapted technologies to control Ultrasonic motor “Smooth Drive ControlTM“
Robotic total station can quickly increase or decrease the motor’s speed. High speed rotation is a USM feature which reduces the rotation time to turn the units to the designated angle, face 1 / face 2 rotation.
Built-in “Smooth Drive ControlTM” technology smooths motion rotation under any conditions. “Smooth Drive ControlTM” technology enhances the durability of the ultrasonic motor. The durability has been confirmed through quality test.
Highly accurate positioning information expands your opportunity!
Straightforward and streamlined field work
Excellent basic performance
Auto-aiming
Precise measurements can be done by a rough aim and a light touch on the “Trigger button” without focusing the lens or doing other operations.
Auto aiming provides consistent accuracy and speed regardless of the operator’s skill levels and other conditions.
Auto-tracking
Enhanced prism-tracking enables you to operate under virtually any Conditions, even when you lose the line-of-sight because of obstructions or strong sunlight.
Even if a prism lock is lost, you can easily turn GT, reacquire the prism with RC-5A and go back to work smoothly.
Maximizing measurements and field performance
Hybrid Positioning Survey System (Upgradable)
Hybrid Switch from Robotic Total Station to GNSS receivers with single-button tap !
Survey Everywhere
If line of sight is not there, we use GNSS. If no open sky, we use the robotic total station.
Hybrid Search
Turns robotic total station toward the prism location based on GNSS position information.
The world’s Smallest and Lightest
This Robotic Total Station is the world’s smallest and lightest. Moreover, it is the same weight as a manual total station. So that it is easier to carry and set up at your projects even in mountains.
Mobility performance is better than before at difficult terrain areas.
* As Robotic Total Station by our research in August 2020
10Hz High rate data communication
Robotic Total Station is able to communicate the data 10Hz speed for survey work purpose. So it enables us to stake out faster than conventional way thanks to high rate data communication.
* The application which is applicable to this function is going to be released.
Trigger key
Just rough aim towards the target prism and lightly press “Trigger button” to precisely aim and measure automatically with ease.
Dustproof and Waterproof: IP65 design
Provides protection from dust and driving rain as well as other inclement weather conditions.
Operates in temperatures from -20 to +50℃.
Large display
Large and high-resolution WVGA display provides clear visibility in sunlight.
Moreover, the large icons improve operability.
Bright, Sharp Guide Light
The Guide Light allows you to instantly recognize the line between the instrument and the stakeout line, with clearly visible Green and Red lights.
